PickGuideMecpow X1 Review: 2W+10W Dual Laser Cutter and Engraver at $789
The Mecpow X1 combines two fundamentally different lasers in one enclosed machine. The 10W 445nm diode handles cutting and engraving on wood, acrylic, and organic materials. The 2W 1064nm infrared laser reaches materials the diode cannot touch — bare metals, glass with coating, and items that reflect blue light. At 5000mm/s max speed with a 0.03×0.03mm infrared focal spot, the X1 is built for users who need the flexibility of both laser types without operating two separate machines.
The Mecpow X1 is a dual-laser cutter and engraver that integrates a 2W 1064nm infrared laser and a 10W 445nm diode laser in a single enclosed body. The infrared laser delivers a 0.03×0.03mm focal spot — one of the tightest available in consumer engravers — enabling fine detail work and engraving on materials that reflect or transmit blue-wavelength light. The diode laser at 0.06×0.08mm focal spot handles cutting up to 8mm wood and 5mm black acrylic. Maximum engraving speed is 5000mm/s via high-frequency galvanometer module. Working area is 105×105mm, expandable to 105×370mm with the Mecpow G1 slide expansion kit. Power input is DC 12V 6A (72W rated). Connectivity is WiFi and USB; software support covers LightBurn, Mecpow Laser (PC), and the Mecpow app on iOS and Android. The enclosure qualifies as Class 1 laser safety. Positioning accuracy is 0.0001mm. Weight is approximately 6.5kg. Compatible with the Mecpow G5 rotary roller and G1 slide extension for expanded material formats. Available in US and EU variants at $789 (sale from $1,299) through mecpow.com.
Pros
- Dual laser — 2W infrared (1064nm) + 10W diode (445nm) covers materials neither laser alone can handle
- 0.03×0.03mm infrared focal spot — extremely tight for fine engraving detail and metal marking
- 5000mm/s max engraving speed via galvanometer module — significantly faster than gantry-based systems
- Class 1 enclosed design — no open laser beam, safer than open-frame machines at this power level
- WiFi connectivity — wireless operation from iOS and Android via Mecpow app
- Compatible with G1 slide extension (expands area to 105×370mm) and G5 rotary roller
- Auto focus and manual focus — both modes available for different workflows
- Cuts up to 8mm wood and 5mm black acrylic with the 10W diode
Cons
- 105×105mm working area is compact — smaller than many open-frame machines in this price range
- At $789 (sale from $1,299) it occupies a higher price point than comparable single-laser machines
- 6.5kg weight and enclosed format mean it's not a portable carry-anywhere device
- Galvanometer-based system means the beam path differs from gantry engravers — learning curve for experienced users
- No built-in fume extraction — the enclosure reduces exposure but does not eliminate smoke from cutting
Who It's For
Good For
- Users who need to engrave metals, glass-coated surfaces, or materials the blue diode cannot mark
- Makers who want dual-material capability (organic materials + metals) in one machine
- Detail engravers who need the 0.03×0.03mm infrared spot for fine text, photo detail, or jewelry marking
- Users who need fast fill speed on complex patterns — 5000mm/s covers dense artwork quickly
- Buyers upgrading from the M1 who want cutting capability and wider material range
Skip If
- Your primary need is large working area — the 105×105mm format is limiting for signs and panels
- You work only with wood and acrylic where a single 10W+ diode covers your material range
- Budget is a constraint — the M1 at $159 covers home engraving needs at a fraction of the price
How It Compares: Mecpow X1 Dual Laser Cutter and Engraver vs Mecpow M1 3.5W/5W Laser Engraver
| Spec | Mecpow X1 Dual Laser Cutter and Engraver | Mecpow M1 3.5W/5W Laser Engraver |
|---|---|---|
| Price | $789 | $159–$179 |
| Laser | 2W Infrared + 10W Diode | 3.5W or 5W Diode |
| Engraving Area | 105×105mm (+G1 ext.) | 100×100mm |
| Max Speed | 5000mm/s (galvo) | 10,000mm/min (gantry) |
| Metal Engraving | Yes (infrared laser) | Limited |
| Best for | Dual-material work, metals, professional speed | Home use, beginners, safety-first |
The X1 is the professional dual-laser step up at $789 — infrared + diode capability, galvanometer speed, and metal engraving. The M1 is the safe beginner choice at $159–$179 for home use on standard materials.
See Mecpow M1 3.5W/5W Laser Engraver →
Verified Ratings
Key Specs
| Infrared Laser | 2W, 1064nm |
| Diode Laser | 10W, 445nm |
| Infrared Spot Size | 0.03×0.03mm |
| Diode Spot Size | 0.06×0.08mm |
| Max Engraving Area | 105×105mm (expandable to 105×370mm with G1) |
| Max Engraving Speed | 5000mm/s |
| Positioning Accuracy | 0.0001mm |
| Power Input | DC 12V, 6A (72W) |
| Connectivity | WiFi, USB |
| Software | LightBurn / Mecpow Laser (PC) / Mecpow App |
| Weight | ~6.5kg |
| Safety | Class 1 Laser (Enclosed) |
| Color | Silver and Orange |
In The Box
- X1 dual laser engraver
- Power adapter (DC 12V 6A)
- USB cable
- Protective laser safety glasses
- User manual
Frequently Asked Questions
Why does the X1 have two lasers instead of one?
The 2W 1064nm infrared laser and 10W 445nm diode laser each have different material interactions. The diode laser at 445nm is absorbed by dark and organic materials — wood, leather, dark acrylic. The infrared laser at 1064nm is absorbed by metals and some coated materials that reflect blue light. Having both in one machine eliminates the need to own two separate units for cross-material workflows.
What does 5000mm/s max speed mean in practice?
The 5000mm/s speed comes from the galvanometer module — a mirror-based scanning system that moves the beam rather than moving the machine head. Galvanometer systems achieve much higher speeds than gantry systems for engraving fills and detail work. For cutting, the machine still moves on the linear rails at standard speeds.
Can the X1 cut metal?
The X1 cannot cut through metal. The infrared laser can mark, anneal, and engrave bare metals and coated metal surfaces. Cutting metal requires fiber lasers at significantly higher power levels. For metal work, the X1 is for surface marking and engraving, not through-cutting.
What is the G1 slide extension and how does it expand the work area?
The Mecpow G1 Slide Extension Kit attaches to the X1 and provides a linear rail that extends the Y-axis. This expands the working area from 105×105mm to 105×370mm — allowing engraving on longer materials like pens, bottles, and narrow panels. The G1 is sold separately at $169.
How does the X1 compare to the M1?
The M1 is a single 3.5W or 5W diode engraver in a 100×100mm format for home and beginner use at $159–$179. The X1 adds a second 2W infrared laser, doubles the diode power to 10W, and brings galvanometer-speed engraving at $789. Choose the M1 for entry-level enclosed engraving; choose the X1 for dual-laser capability and professional-grade speed.
Verdict
The Mecpow X1's dual-laser design is its defining feature, and it earns its price in the specific use cases where one laser type isn't enough. The 0.03×0.03mm infrared spot and 5000mm/s galvanometer speed are real capabilities, not spec inflation. At $789 (reduced from $1,299), it's a serious machine for makers who need to engrave materials across the spectrum — metals, organics, and coated surfaces — without switching equipment.
